Features
Car Dimension Checking - If the car fits
fully inside the gauge, then the car meets the standard dimensional
limits (max 2-3/4” width, max
7” length, and min 1-3/4” wheel spacing). The
height limit is set to 5". You can change the height limit
by drilling two holes or remove the height checker. Length
can be adjusted with washers
Underbody Clearance Checking - The Clearance
Checker is 3/8" high. If the bottom of the car rubs on
the Clearance Checker, then it does not have the proper clearance.
Wheelbase Checking - If you have restrictions
on the car wheelbase, marks can be made on the side panels
for comparison against the car wheelbase.
Start Pin Checking –If the front of
the car extends past the leading edge of the start pin then
it will have an unfair advantage.
|
